Touch-Screen Sauna Controller for Wholesale Supply
This non-WIFI sauna controller is offered for retailers, distributors and sauna project buyers. The documented system uses a touch-screen control panel, a selected power unit and a separate temperature sensor for compatible sauna-heater installations.
The technical values below apply only to the reviewed controller configurations and must not be generalized to other controllers or heater systems.
Verified Control Panel Specification
| Temperature regulation range | 40-110°C |
|---|---|
| Control panel dimensions | 103 × 125 × 27 mm |
Documented Power Unit Configurations
| Power unit | 230 V 1N~ maximum load | 400 V 3N~ maximum load |
|---|---|---|
| CL32WF-C | 9 kW | 18 kW |
| CL50WF-C | 9 kW | 30 kW |
| CL40WF-R | 9 kW | 12 kW |
The maximum load depends on the selected power unit and electrical configuration. Buyers must confirm voltage, phase, load and compatible heater specification before ordering.
Power Unit and Sensor Dimensions
| CL-C power unit dimensions | 340 × 300 × 130 mm |
|---|---|
| CL-R power unit dimensions | 270 × 273 × 80 mm |
| Resettable overheat protector | 150°C |
| Temperature sensor dimensions | 50 × 72 × 28 mm |
Controller System Scope
The reviewed non-WIFI controller does not include a door-switch function or WIFI control. Temperature and operating time are adjusted from the touch-screen control panel.
The sauna heater is not included. Product images are visual references and do not establish inclusion of a heater or compatibility with every sauna heater.
Electrical and Installation Boundaries
The controller is documented only for the power-unit configurations shown above. No other voltage, phase, frequency or maximum-load value is implied.
Wiring, sensor placement, compatibility and installation requirements depend on the selected heater and project. Confirm the applicable documentation and use appropriately qualified installation personnel; this product description is not an installation guide.
Order Confirmation
Before ordering, confirm the selected power unit, electrical configuration, connected heater load, controller-system components and current product specification in writing.
Request a Sauna Controller Quote
Contact Mai Sauna to confirm the required controller and power-unit configuration, compatibility information, current specification and B2B quotation.
